Floor board - Plans and dimensions.

By Tony Slattery

Although there are suppliers out there such as Whitworth Shop who are able to supply full sets of floor boards for your Y, you may only need to replace one or may want the satisfaction of making your own, or the cost of shipping is prohibitive.  Whatever the reason you wish to make your own set up, Tony Slattery will be bring us the necessary technical drawings to enable you to make them up from scratch. These will be added to as Tony is able to do them.

Plans currently available are:

To print a plan, first open the plan, then right click on the plan and select SAVE AS and save it to your hard disk. To return to this page, use your browser's BACK button.
	Y T Strengthener - Inner wing (behind check strap securing loop to inside of rear wheel arch). These are 'handed' and this one is for the Right hand side of the car. Click here for a PDF file version.
	Y T Strengthener - Inner wing (behind check strap securing loop to inside of rear wheel arch). These are 'handed' and this one is for the Left hand side of the car. Click here for a PDF file version.

While the basic floorboards are very similar, there are marginal differences between RIGHT HAND DRIVE to LEFT HAND DRIVE, and Y/YB versus Y/T. We are in the long and complicated process of compiling these drawings. More will be added here as they become available from Tony Slattery. These files are all PDF files.
